2 Channel Pressure sensor input io module

Isolation withstand voltage: 500V

Vibration test: according to EN 60068-2-6

Impact test: according to EN 60068-2-27

Electromagnetic compatibility test: in accordance with EN 61000-4

Protection class: IP20

Operating temperature: - 25°C~+60° C

Storage temperature: - 40°C~+85°C

Relative humidity: 95%, non-condensing

Contact us

product details

download

Parameters

LC3162 Pressure sensor input module Electrical parameters
Number of channels	2	Resolution/Accuracy	16bit/0.2%
Signal range	0-10mv	Sampling frequency	150Hz
Signal type	Differential/single-ended	System side current consumption	210mA
line type	2-WIRE SYSTEM	Reverse circuit protection	support
Excitation power output	5V DC	Module failure alarm	support
