01

8-Channel Voltage Input Ethercat IO Module

Withstand Voltage: 500V

Vibration Testing: Complies with EN 60068-2-6 standard

Shock Testing: Complies with EN 60068-2-27 standard

Electromagnetic Compatibility Testing: Complies with EN 61000-4 standard

Protection Rating: IP20

Operating Temperature: -25°C to +60°C

Storage temperature: -40°C to +85°C

    Contact us
    product details

    Specification parameters

    LD3138 Voltage Input Module   Specifications
    Electrical Parameters
    Number of Channels 8 Resolution/Accuracy 16-bit/0.2%
    Signal Range ±10V Sampling Frequency 3.125 kHz
    Signal Type Differential/Single-ended System-Side Current Consumption 125mA
    Connection Type 2-wire Reverse Circuit Protection Supported
    Input Impedance >500KΩ Module Fault Alarm Supported
