ATX industrial mainboard Q670 Windows 10 Linux
product description
Specification parameters
| LQ1276-Q670 Specification | |
| System | |
| Processor | Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® processors (12th/13th/14th Gen), supporting up to 125W TDP |
| Memory | 4x DDR5-3600/4000/4400MHz, U-DIMM slots, supporting up to 128GB (Non-ECC) |
| Graphics | Intel® integrated graphics |
| Storage | 4x SATA 3.0 (RAID 0/1/5/10), 1x M-Key M.2 2242/2280 (PCIe x1) Gen4, 1x M-Key M.2 2242/2280 (PCIe x4) Gen4 |
| Operating System | Windows 10, Linux |
| Watchdog Timer | Programmable 255-level timer interval, from 1 to 255 seconds/minutes |
| External Interface | |
| Network Port | 1x RJ45 1219-VIntel (10/100/1000 Mbps)PHY, 1x RJ45 1225-VIntel® (10/100/1000/2500 Mbps) |
| Display | 2x HDMI 2.0: Maximum resolution 4096x2160@60Hz 1x VGA: Maximum resolution 1920x1200@60Hz |
| Audio | 1 xLine-in,1xLine-out,1x Mic-in |
| Serial Port | 1xRS232/422/485(with auto flow control),1x RS232 |
| USB | 4x USB3.2 GEN2，2xUSB3.2 GEN1 |
| Internal Interface | |
| Expansion Interfaces | 2x PCIe x16 (GEN4, x16 physical slots, x8 signals), 4x PCIe x4 (GEN3), 1x PCI |
| USB | 2xUSB3.2 GEN1 pin header,2xUSB2.0 pin header,2xUSB2.0(Internal Type-A straight plug) |
| SATA | 4x SATA3.0 |
| Serial Port | 4x RS232 pin header |
| GPIO | 1x8bit programmable GPlO |
| PS2 | 1xPS/2 |
| Fan Header | 1x CPU fan, 3x system fans |
| Environment | |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | Operating humidity: 95% at 40°C, non-condensing Storage humidity: 95% at 60°C, non-condensing |
| Power Supply | |
| Power Supply Input | ATX Power Supply |
| Institution | |
| Dimensions | 304.8x244 mm |
| Certification | |
| Safety Certification | CE, FCC |
Who is Lingchen? Can I trust a new supplier?
Suzhou Lingchen acquisition computer Co. LTD was established in 2006 and is located in suzhou city jiangsu provinceChina,enjoying convenient transportation and beautiful environment. Our company covers an area of 25000 square meters and has 420 employees. Our main products include industrial computer, PLC,Motion control card,remote lO,linear motor.Besides, we are making great efforts to develop new products to meet different requirements. In order to provide customers with satisfactory products and services, we have established a modern quality management system according to international standards.Our company has oscilloscope,high and low temperature test chamber.Motion control test bench equipment to strictly control the product quality.
