Micro ATX Industrial Mainboard 64-bit Windows 10
product description
Specification parameters
| LH43-3000 Specification | |
| System | |
| Processor | HaiGuang 3250, 2.8GHz, 8C/16H, 90W HaiGuang 3350, 3.0GHz, 8C/16H, 90W |
| Memory | 4x DDR4 U-DIMM 2666MHz, supports up to 512GB (ECC-enabled) |
| Storage | 3x SATA 3.0, 1x M.2 Socket (PCIe x1) |
| Operating System | Windows 10 (64-bit), Linux (Ubuntu/Kylin/UOS) |
| External Interface | |
| Network Port | 2x RJ45 (10/100/1000 Mbps) |
| Display | 1x HDMI,1x VGA |
| Audio | Line in& Line out& Mic in |
| Serial Port | 1xCOM(RS232),1xCOM(RS232/422/485) |
| USB | 4x USB3.0,4x USB2.0 |
| Internal Interface | |
| Expansion Interfaces | 1*MiniPCle(PCleX1/USB2.0);1*PCleX1;1*PCleX4 ;1*PCleX16 |
| Display Interface | 1x LVDS |
| USB | 2x USB2.0 |
| SATA | 3x SATA 3.0 7-pin connectors |
| Serial Port | 7xCOM(RS232);1xCOM(RS232/422/485) |
| GPIO | 1x 8bit programmable GPlO |
| PS/2 | Keyboard & Mouse |
| Front Interface | 1x Front Panel Power SW |
| Fan Header | 4x FAN |
| Environment | |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -55°C to 85°C |
| Humidity | 95%, non-condensing |
| Power Supply | |
| Power Supply Input | Standard ATX power supply |
| Institution | |
| Dimensions | 244x244 mm |
| Certification | |
| Part Number | Product Information |
| LH43-3250-C10 | 3250 (8-core)/2.8GHz/1x HDMI/1x VGA/1x LVDS/2x LAN/10x COM/4x USB 3.0/6x USB 2.0/1x Audio/85W (typical power consumption) |
| LH43-3250-C6 | 3250 (8-core)/2.8GHz/1x HDMI/1x VGA/1x LVDS/2x LAN/6x COM/4x USB 3.0/4x USB 2.0/85W (typical power consumption) |
| LH43-3350-C10 | 3350 (8-core)/3.0GHz/1x HDMI/1x VGA/1x LVDS/2x LAN/10x COM/4x USB 3.0/6x USB 2.0/1x Audio/80W (typical power consumption) |
