Micro-ATX Industrial Mainboard H610 Windows 10 Linux
product description
Specification parameters
| LH1243-H610 Specification | |
| System | |
| Processor | Intel® 12th/13th/14th Gen Core i9/i7/i5/i3/Pentium®/Celeron® processors, supporting up to 125W TDP |
| Memory | 2x DDR5-4800/5200/5600MHz, U-DIMM slots, supporting up to 64GB (Non-ECC) |
| Graphics | Intel® integrated graphics |
| Storage | 4x SATA 3.0, M-Key M.2 2242/2280 (PCIe x1) |
| Operating System | Windows 10, Linux |
| Watchdog Timer | Programmable 255-level timer interval, from 1 to 255 seconds/minutes |
| External Interface | |
| Network Port | 1x RJ45 1219-VIntel® (10/100/1000 Mbps)PHY, 1x RJ45 1225-Vintel® (10/100/1000/2500 Mbps) |
| Display | 2x HDMI 2.0: Maximum resolution 4096x2160@60Hz. 1x VGA: Maximum resolution 1920x1200@60Hz. |
| 1xLine-in,1xLine-out,1xMic-in | |
| Serial Port | 1xRS232/422/485(with auto flow control),1x RS232 |
| USB | 4xUSB3.2 GEN1,2xUSB2.0 |
| Internal Interface | |
| Expansion Interfaces | 1x PCIe x16 (Gen3), 1x PCIe x4 physical slot (x1 signal), 1x PCIe x1, 1x PCIe x4 (x4 signal), M-Key M.2 2242/2280 (PCIe x1) |
| USB | 2x USB 2.0, 1x USB 2.0 (internal Type-A direct-plug) |
| SATA | 4x SATA3.0 |
| Serial Port | 4x RS232 pin header |
| GPIO | 1x 8bit programmable GPlO |
| TPM | TPM2.0 SPl pin header |
| Power Switch/Power LED | 1xPS/2 |
| Fan Header | 1x CPU fan, 2x system fans |
| Environment | |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | Operation humidity: 95%@40°C, non-condensing Storage humidity: 95%@60°C, non-condensing |
| Power Supply | |
| Power Supply Input | ATX Power Supply |
| Institution | |
| Dimensions | 244x244 mm |
| Certification | |
| Safety Certification | CE, FCC |
