Mini-ITX Industrial mainboard H610/H610E Windows 10 Linux
product description
Specification parameters
| LH1211-H610 Specification | |
| System | |
| Processor | Intel® 12th/13th/14th Gen Core i9/i7/i5/i3/Pentium®/Celeron® LGA1700 processors, supporting up to 65W TDP |
| Chipset | H610/H610E |
| Memory | 2x DDR5 SO-DIMM slots, 4800/5200/5600 MHz, supporting up to 64GB |
| Graphics | Intel® Integrated Graphics |
| Storage | 2x SATA 3.0, 1x M.2 2242/2280 (PClex4) |
| Operating System | Windows 10, Linux |
| Watchdog Timer | Programmable 255-level timer interval, from 1 to 255 seconds/minutes |
| External Interface | |
| Network Port | 1x R45® 1219-V Intel® (10/100/1000 Mbps)PHY, 1xRJ45® 1226-V Intel® (10/100/1000/2500 Mbps), 2x RJ45®1210-ATIntel®(10/100/1000 Mbps) |
| Display | 2x HDMI 1.4: Maximum resolution 4096x2160 @ 60Hz, 1x VGA: Maximum resolution 1920x1200 @ 60Hz |
| Serial Port | 1x RS232/422/485 (with auto flow control), supports 5V/12V voltage output, default power-off; 1x RS232 |
| USB | 4xUSB3.2 Gen1,2xUSB2.0 |
| Internal Interface | |
| Expansion Interfaces | 1x PCIe x16 Slot (Gen4, x16 signal) 1x E-Key M.2 2230 Slot (PCIe x1 / USB 2.0) |
| USB | 2x USB 2.0 (1-pin header to 2 ports), 1x USB 2.0 (internal Type-A direct plug-in) |
| SATA | 2xSATA3.0 |
| Serial Port | 4xRS232(Pin Header) |
| GPIO | 1x 8bit programmable GPlO |
| TPM | Supports optional TPM 2.0 expansion |
| Front Panel Connectors | 1x front panel power switch/Reset/Power LED indicator/HDD LED indicator |
| Power Switch/Power LED | Power Switch and Power LED (2 x PH2.0 sockets) |
| Fan Header | 1x CPU fan (4-pin, supports smart fan), 1x SYS fan (4-pin, supports smart fan) |
| Environment | |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | Operation humidity: 95%@40°C, non-condensing Storage humidity: 95%@60°C, non-condensing |
| Power Supply | |
| Power Supply Input | ATX Power Supply |
| Institution | |
| Dimensions | 170x170 mm |
| Certification | |
| Safety Certification | CE, FCC |
